Inspecting Fractionation Towers
By Juan Manuel Sanchez, Álvaro Valverde, Carlos Di Marco and Eduardo Carosio, YPF S.A.
Distillation columns are often workhorses in the chemical process industries (CPI), and at times, it is necessary to physically inspect the interior of a column. This article demonstrates what an inspection can reveal, by sharing the experience of actual fractionation-tower inspections in a petroleum refinery. The points mentioned are intended to provide guidance to future tower inspectors, so that they can focus on extremely important and relevant points that will directly impact the operation of distillation columns. Typically, inspections are carried out by a number of different departments, each one focused on its particular area of concern. Column components are usually inspected by the equipment inspection department. The production department, besides checking if it is necessary to replace or repair internals, inspects if the tower is clean or if it has accumulated large quantities of coke, salt or corrosion products during operation. Cleaning, repairs and mountings are the responsibility of the maintenance department. A critical inspection is a tedious and often dirty task. It is necessary to remain inside the tower for hours. A job well-done, however, can identify potential problems and will save headaches when the tower is back in operation. »
|
 |
